Pt1000TR160/C, sonda de temperatura, cable 5 m
Sonda hermética (IP67)de bajo coste para múltiples usos -30 a +80°C.
Tolerancia t = ±(0.30+0.005*|t|) - clase B de conformidad con la norma IEC751. Carcasa de poliamida con cable apantallado de PVC de longitud específica. Carcasa diámetro 6mm, longitud 20mm. Diámetro del cable 3. Con conector CINCH.
-
códigoSN201C
Datos técnicos
Valor Medido
Temperatura
TEMPERATURE SENSOR
Measuring range
-30 to +80 °C
Accuracy
± (0.3 + 0.005 t) at °C
Accuracy class
A
Time response
t0.5 <12 s (in flowing water at > 0.2 m/s)
t50 <12s, t90 <32s (in liquid)
t50 <12s, t90 <32s (in liquid)
Type of sensing element
Pt1000
Temperature coefficient
3850 ppm / °C
GENERAL TECHNICAL DATA
Wire connection
2-wire connection
Material of the case
POLYAMIDE-based plastic
Dimensions of the case
length 20 mm;
diameter 5.7 ± 0.1 mm
diameter 5.7 ± 0.1 mm
Lead-in cable
PVC shielded
Length of lead-in cable
5 meters
Connector
CINCH
IP protection
IP67
Warranty
30 months
