Multilogger Ethernet - Datalogger universal con 4 entradas

Battery powered datalogger with 4 universal inputs for measurement of 0-10V voltage, 0-20mA current, two-state signal and for counting pulses.
Signals are connected to four detachable terminal blocks.
Multilogger can be installed permanently to Ethernet network or work as portable device.
Included is traceable calibration certificate in accordance with EN ISO/IEC17025.

Datalogger alimentado por batería con 4 entradas universales para la medición de voltaje 0-10V, corriente 0-20mA, señal de dos estados y para conteo de pulsos.

Las señales están conectadas a cuatro bloques de terminales desmontables.

El Multilogger se puede instalar de forma permanente en la red Ethernet o puede funcionar como dispositivo portátil.

Se incluye un certificado de calibración rastreable de acuerdo con EN ISO / IEC17025.

El Multilogger es un registrador de datos a batería capaz de medir y registrar valores eléctricos y de sensores a través de sus entradas.

Los valores medidos se pueden ver en un navegador web, así como almacenar y descargar para un análisis posterior.

código

M1300
Garantía

3 años

Send request

Datos técnicos

Valor Medido

Corriente

Voltaje

Dos estados binarios

Pulsos

Rango temperatura de funcionamiento -10 a +60°C

Rango humedad de funcionamiento 5% a 85%RH, sin condensación

Compensación de temperatura del sensor de humedad todos los rangos de temperatura

Intervalo de medición 1s a 24 horas

Unidades de temperatura disponibles grados Celsius, grados Fahrenheit

Valores calculados punto de condensación, humedad absoluta, humedad específica, proporción de mezcla, entalpía específica

Capacidad de memoria(aprox.) 1 000 000 valores (grabación no ciclica), 600 000 valores (grabación ciclica)

Protección IP IP20

Interfaz de comunicación Ethernet, USB, RS232

Protocolos de comunicación Ethernet WWW, SNMPv1, XML, DATALINK

Protocolos de alarma E-Mail

Configuración Comet Vision, configuración WWW

Alimentación adaptador AC 230Vac/5Vdc (necesario para la interfaz Ethernet)

Batería NiMH 3x pilas recargables 1.2V AA (copia de seguridad o aplicaciones portátiles) ó 3x pilas alcalinas 1.5V AA (para aplicaciones portátiles)

Conector de alimentación coaxial, diámetro 5.5 x 2.1mm

Dimensiones 178 x 95 x 37mm (W x H x D), sin cables conectados

Características

Applications:

Healtcare and laboratories - Monitoring of storage areas at temperatures up to -200 °C.

Food industry - Monitoring of critical processes according to the HACCP standard with the possibility of prompt notification of unforeseen events that could lead to the degradation of the goods.

Industry and production - monitoring temperature and humidity in food, pharmaceutical, aerospace etc.

Production facilities and warehouses - Monitoring of storage conditions and production processes in the temperature range -200 ° C to + 600 ° C. Sending data to COMET Database or SCADA third-party systems.

Metrology - COMET sensors together with COMET radiationshields are the ideal basis for weather stations for long-term weather, climate and air monitoring.

Data centers, server rooms - Temperature and humidity monitoring, data center monitoring, RACK stands, including flood status reports, opening / closing of doors (windows), motion, smoke. SNMP monitoring, remote alarms by email and Syslog.

Building management - Our instruments which measure temperature, humidity, atmospheric pressure and CO2 are an integral part of these industry-leading solutions.

Features description:

● the features may vary depending on the device type

● up to 6 hardware inputs for measuring and recording, 16 virtual channels for temperature, humidity, dew point, atmospheric pressure, current 0 - 20 mA and voltage 0 - 10 V (-60 to 140 mV), two-state events, pulses, CO2
● memory for 1 million values
● indication of alarm conditions via e-mail, SMS, integrated acoustic siren LEDs, stwo-state output to control other devices
● analytical software for data processing and configuration - COMET Vision
● communication interfaces - USB, RS232 and Ethernet (SNMPv1 and XML)

Up to 4 physical Inputs - TERMINALS

Removable terminal blocks allows connection of:

Sensors with voltage output (range 0-10 V; accuracy ±10 mV)
Sensors with current output (range 0-20 mA; accuracy ±20 µA)
Sevices with two-state output (potential-less contact or voltage signal 0-30V); may be applied to input 3 and 4
Devices with pulse signal (potential-less contact or voltage signal 0-30V); may be applied to input 4

Evaluation of up to 16 variables

Up to 16 variables may be calculated from the four connected probes / sensors. This is the sum of the measured and calculated values. The calculated values can be a further expression of moisture – dew point temperature, absolute humidity, specific humidity, mixing ratio, specific enthalpy. It can be also the result of inter-channel conversions, e.g. the difference of two connected temperature probes.Multilogger LCD display detail.

The measured values are stored in the internal non-volatile memory. Memory capacity is up to 1 million values. Logging mode can be adjusted as non-cyclic, when logging stops after filling the memory, or cyclic, when after fulfilling the memory oldest stored values are overwritten by new ones.

Measured values are displayed on the screen with backlight option and the ability to change the size of display digits

Power supply

Multilogger can be powered by AC adapter or by rechargeable batteries with charging capability. Batteries are always a part of the device (you can also use standard alkaline AA batteries). Batteries power the device for several months.

While using the AC adapter, the batteries provide backup operations and provide recording and measurement during power failure. Thanks to the Ethernet output the device informs about the failure via e-mail message.

Alarm limits and alarm indication

It is possible to set two independent alarm limits for each channel (i.e. measured or calculated value).

Alarm signalization can be acoustic (built-in beeper), optical, sending an e-mail alert or an alarm output. The alarm output is for connecting an external audio or visual alarm.

Communication interfaces

Multilogger is always equipped with USB connector for communication, data analysis and also for charging of the rechargeable batteries.

Included Ethernet interface allows to:

send an e-mail when an alarm state starts or ends
use DATALINK: display current values or download values from memory to COMET Database in your PC. Software COMET Database contains many useful tools for data analysis - graphs, tables, statistics, etc.
simple wireless communication with Wi-Fi TP-LINK router
third-party applications to read the actual measured values using universal protocols SNMPv1 and XML
view current measured values using your web browser

Output ALARM OUT

Multilogger - Alarm limits and alarm indication

Output can be used for controling other devices when alarm is launched, such as external buzzer, telephone dialer etc.
Type of output - open collector transistor
Max. switching current - 100 mA
Max. voltage on output - 24 V
Auxiliary voltage at terminal - +5 V (only when the mains supply is present)
Users can receive alarms if the values go outside the paramters set. Alarms are indicated through an internal buzzer , 3 LEDs or email alerts via Ethernet port.
